Smart-Line - swing corner to round beams ‘oblique’

Round swing connector type 'oblique'

The square corner connector is designed to build rectangular swing frames made of round wood beams. Material thickness is approximately 2 mm, whereas the length of the pipes is 200 mm. Mounting holes have diameter of 10 mm. Ideal for horizontal beam with diameter of 100mm and vertical poles with diameter of 80mm. The angle between vertical beams = 60 °. The angle between horizontal beam and leg = 100°. Simply and easy mounting - just slide it into the beams, fasten it with the appropriate screws, done!

Exact dimensions:

Product tested and approved in accordance with TÜV NORD certificate, which provides the highest safety for your child..
